| A1-A2 Cable
Glands |
 |
| Standard |
BS 62444 : 2013
|
| Application |
Outdoor or indoor for
use with all types of unarmoured cable.
|
| Function |
Produce seal on outer
sheath of the unarmoured Cable |
| Ingress
Protection |
IP66 with Nitrile Thread
Seal EN 60529 |
| Material
|
Brass BS 2874 CZ121 Pb3 |
| Options |
IP Rating : IP68,
3 bar with fibre or nylon with thread
seal EN 30529
Thread : ET NPT BSP DSPT PG
Plating: Nickel (NP) Chrome (TP) Zinc
(ZP) Tin (TP)
Material :Brass casting BS 2874 ,
Aluminium alloy Stainless steel 316
Seals: PCP black Silicon orange |
| Operating
Temp. |
Standard seals -20o
C to +80o C
Extended seals - 60o C to
+ 180o C |
| Cable
Type |
unarmoured |
| Accessories
|
Refer to page Accessories
for Cable Glands |
| |
| Available
in both loose piece & packed form,
please specify & refer to page Cable
Gland Kit |
|
| |
 |
| |
| |
|
| |
| BWL Cable
Glands |
 |
| Standard |
BS 6121-1
: 2005 |
| Application |
Dry Indoor, for use with
all types of SWA extruded bending Cable
|
| Function |
Provides mechanical
cable retention & electrical continuity
via armoured wire termination |
| Ingress
Protection |
IP2X EN 60529 |
| Material
|
Brass BS 2874 CZ121 Pb3 |
| Options |
Thread : ET NPT
BSP DSPT PG
Plating: Nickel (NP) Chrome (TP) Zinc
(ZP) Tin (TP)
Material :Brass casting BS 2874 ,
Aluminium alloy Stainless steel 316
|
| Operating
Temp. |
Standard seals -80o
C to +300o C |
| Cable
Type |
SWA extruded bending
Cable |
| Accessories
|
Refer to page Accessories
for Cable Glands |
| |
| Available
in both loose piece & packed form,
please specify & refer to page Cable
Gland Kit |
|
| |
 |
|
| |
| BWE-CIEL
Cable Glands |
 |
| Standard |
BS 6121-1
: 2005 |
| Application |
Dry Indoor, for use with
all types of SWA extruded bending Cable
|
| Function |
Provides mechanical
cable retention & electrical continuity
vie armoured wire termination &
integral Earth facility complete with
Brass earth bolt & washer |
| Ingress
Protection |
IP2X EN 60529 |
| Material
|
Gland Body: Brass casting
HTB1
Gland nut : Brass BS 2874 CZ121 Pb3
|
| Options |
Thread : ET NPT
BSP DSPT PG
Plating: Nickel (NP) Chrome (TP) Zinc
(ZP) Tin (TP)
Material :Brass casting BS 2874 ,
Aluminium alloy Stainless steel 316 |
| Operating
Temp. |
Standard seals -20o
C to +300o C |
| Cable
Type |
SWA extruded bending
Cable |
| Accessories
|
Refer to page Accessories
for Cable Glands |
| |
| Available
in both loose piece & packed form,
please specify |
|
| |
 |
|
| |
| BWC Cable
Glands |
 |
| Standard |
BS 6121-1-2005
|
| Application |
Dry Indoor, for use with
all types of SWA extruded Bending Cable
|
| Function |
Provides mechanical
Cable retention& electrical continuity
via armoured wire termination. |
| Ingress
Protection |
IP2X EN 60529 |
| Material
|
Brass BS 2874 CZ121 Pb3
|
| Options |
Thread : ET NPT BSP DSPT
PG
Plating: Nickel (NP) Chrome (TP) Zinc
(ZP) Tin (TP)
Material :Brass casting BS 2874 , Aluminium
alloy Stainless steel 316 |
| Operating
Temp. |
-80o C to
+ 300o C |
| Cable
Type |
SWA Extruded Bending
Cable |
| Accessories
|
Refer to page Accessories
for Cable Glands |
| |
|
| Available
in both loose piece & packed form,
please specify & refer to page Cable
Gland Kit |
|
| |
 |
|
| |
| CW Cable
Glands |
 |
| Standard |
BS 62444
: 2013 |
| Application |
For indoor or outdoor
use with all types of SWA extruded Bending
Cable |
| Function |
Providing environmental
seal in the cable outer Sheath. Also
provides mechanical cable retention
& electrcal continuity via armoured
wire termination. |
| Ingress
Protection |
IP66 with Nitrile thread
seal EN 60529 |
| Material
|
Brass BS 2874 CZ121 Pb3 |
| Options |
IP Rating : IP68,
3 bar with fibre or nylon with thread
seal EN 60529
Thread : ET NPT BSP DSPT PG
Plating: Nickel (NP) Chrome (TP) Zinc
(ZP) Tin (TP)
Material :Brass casting BS 2874 ,
Aluminium alloy Stainless steel 316
Seals: PCP black Silicon orange |
| Operating
Temp. |
Standard seals -20o
C to + 80o C
Extended seal - 60o C to
+ 180o C |
| Cable
Type |
SWA extruded bending
Cable |
| Accessories
|
Refer to page Accessories
for Cable Glands |
| |
| Available
in both loose piece & packed form,
please specify & refer to page Cable
Gland Kit |
|
| |
 |
|
| |
| CWE-
CIEL Cable Glands |
 |
| Standard |
BS 62444
: 2013 |
| Application |
For indoor or outdoor
use with all types of SWA extruded Bending
Cable |
| Function |
Providing environmental
seal in the cable outer Sheath. Also
provides mechanical cable retention
& electrical continuity via armoured
wire termination & integral earth
facility complete with Brass earth
bolt & washer. |
| Ingress
Protection |
IP66 with Nitrile thread
seal EN 60529 |
| Material
|
Gland Body: Brass casting
HTB1
Gland nuts : Brass BS 2874 CZ121 Pb3
|
| Options |
Thread : ET NPT
BSP DSPT PG
Plating: Nickel (NP) Chrome (TP) Zinc
(ZP) Tin (TP)
Material :Brass casting BS 2874 ,
Aluminium alloy Stainless steel 316
Seals: PCP black Silicon orange |
| Operating
Temp. |
Standard seals -20o
C to + 80o C
Extended seal - 60o C to
+ 180o C |
| Cable
Type |
SWA extruded bending
Cable |
| Accessories
|
Refer to page Accessories
for Cable Glands |
| |
| Available
in both loose piece & packed form,
please specify & refer to page Cable
Gland Kit |
|
| |
 |
|
| |
| D1W Cable
Glands |
 |
| Standard |
BS 62444
: 2013 |
| Application |
For indoor or outdoor
use with all types of SWA extruded Bending
Cable |
| Function |
Providing environmental
seal in the cable outer Sheath. Also
provides mechanical cable retention
& electrical continuity via armoured
wire termination. |
| Ingress
Protection |
IP66 with Nitrile thread
seal EN 60529 |
| Material
|
Brass BS 2874 CZ121
Pb3 |
| Options |
IP Rating : IP68,
3 bar with fibre or nylon with thread
seal EN 60529
Thread : ET NPT BSP DSPT PG
Plating: Nickel (NP) Chrome (TP) Zinc
(ZP) Tin (TP)
Material :Brass casting BS 2874 ,
Aluminium alloy Stainless steel 316
Seals: PCP black Silicon orange |
| Operating
Temp. |
Standard seals -20o
C to + 80o C
Extended seal - 60o C to
+ 180o C |
| Cable
Type |
SWA extruded bending
Cable |
| Accessories
|
Refer to page Accessories
for Cable Glands |
| |
| Available
in both loose piece & packed form,
please specify & refer to page Cable
Gland Kit |
|
| |
|
|
| |
| E1W Cable
Glands |
 |
| Standard |
BS 62444
: 2013 |
| Application |
For indoor or outdoor
use with all types of SWA extruded Bending
Cable |
| Function |
Providing environmental
seal on both the cable inner &
outer Sheaths. Also provides mechanical
cable retention & electrical continuity
via armoured wire termination. |
| Ingress
Protection |
IP66 with Nitrile thread
seal EN 60529 |
| Material
|
Brass BS 2874 CZ121
Pb3 |
| Options |
IP Rating : IP68,
3 bar with fibre or nylon with thread
seal EN 60529
Thread : ET NPT BSP DSPT PG
Plating: Nickel (NP) Chrome (TP) Zinc
(ZP) Tin (TP)
Material :Brass casting BS 2874 ,
Aluminium alloy Stainless steel 316
Seals: PCP black Silicon orange |
| Operating
Temp. |
Standard seals -20o
C to + 80o C
Extended seal - 60o C to
+ 180o C |
| Cable
Type |
SWA extruded bending
Cable |
| Accessories
|
Refer to page Accessories
for Cable Glands |
| |
| Available
in both loose piece & packed form,
please specify & refer to page Cable
Gland Kit |
|
| |
 |
|
| |
| E1WE-CIEL
Cable Glands |
 |
| Standard |
BS 62444
: 2013 |
| Application |
For indoor or outdoor
use with all types of SWA extruded Bending
Cable |
| Function |
Providing environmental
seal on both the cable inner &
outer Sheaths. Also provides mechanical
cable retention & electrical continuity
via armoured wire termination &
integral earth facility complete with
brass earth bolt & washer. |
| Ingress
Protection |
IP66 with Nitrile thread
seal EN 60529 |
| Material
|
Brass BS 2874 CZ121
Pb3 |
| Options |
Thread : ET NPT
BSP DSPT PG
Plating: Nickel (NP) Chrome (TP) Zinc
(ZP) Tin (TP)
Material :Brass casting BS 2874 ,
Aluminium alloy Stainless steel 316
Seals: PCP black Silicon orange |
| Operating
Temp. |
Standard seals -20o
C to + 80o C
Extended seal - 60o C to
+ 180o C |
| Cable
Type |
SWA extruded bending
Cable |
| Accessories
|
Refer to page Accessories
for Cable Glands |
| |
| Available
in both loose piece & packed form,
please specify & refer to page Cable
Gland Kit |
|
| |
 |
|
| |
| AXE Cable
Glands |
 |
| Standard |
BS 62444
: 2013 |
| Application |
Outdoor or Indoor for
use with all types of flexible wire
braid cable |
| Function |
Produces seal on
outer sheath of the flexible wire
braid cable and clamping of wire braid
for electrical continuity |
| Ingress
Protection |
IP66 with Nitrile thread
seal EN 60529 |
| Material
|
Brass BS 2874 CZ121
Pb3 |
| Options |
Thread : ET NPT
BSP DSPT PG
Plating: Nickel (NP) Chrome (TP) Zinc
(ZP) Tin (TP)
Material :Brass casting BS 2874 ,
Aluminium alloy Stainless steel 316
Seals: PCP black Silicon orange |
| Operating
Temp. |
Standard seals -20o
C to + 80o C
Extended seal - 60o C to
+ 180o C |
| Cable
Type |
Flexible wire braid Cables |
| Accessories
|
Refer to page Accessories
for Cable Glands |
| |
| Available
in both loose piece & packed form,
please specify & refer to page Cable
Gland Kit |
|
| |
 |
|
| |
| |
| CWA Cable
Glands |
 |
| Standard |
BS 62444
: 2013 |
| Application |
For indoor or outdoor
use with all types of AWA or ASA extruded
bending Cable |
| Function |
providing environmental
seal on the cable outer sheath. Also
provide mechanical cable retention &
electrical continuity via Aluminium
armoured wire for strip termination
|
| Ingress Protection
|
IP66 with Nitrile thread
seal EN 60529 |
| Material |
Aluminium Alloy |
| Options |
IP Rating : IP68, 3 bar
with fibre or nylon thread seal EN 60529
Thread : ET NPT BSP BSPT PG
Clamps : Aluminium wire armour AWA for
BWA
Aluminium strip armour cable ASA for
BY
Seals : PCP black Silicon orange
Clamps : Aluminium armour wire AWA for
CWA
Aluminium strip armour cable ASA for
CY |
| Operating
Temperature |
Standard Seals - 20o C
to + 300o C
Extruded seals - 60o C to + 80o C |
| Cable Type
|
AWA or ASA extruded bending
cable |
| Accessories |
refer page for Accessories
for Cable Glands |
| |
| Available in both loose
piece & packed form, please specify
& refer Cable Gland Kit |
|
| |
 |
|
| |
| Brass Cable
Glands as per SABS and AS |
 |
| Application |
Outdoor or
Indoor for use with all type of armoured
braided or unarmoured electrical cable
fittings. |
| Ingress
Protection |
IP30 IP66 IP68 (5 bar) |
| Options |
Thread : ISO Metric
ET NPT NPS BSP DSPT PG
Clamps: SWA (E1W) SWB (E1X) STA (E1Z)
Plating: Electroplated Nickel (NP)
Zinc (ZP) Chrome (TP) Tin (TP) |
| Material |
Brass BS 2874 CZ121 Pb3
& Stainless Steel 316 |
| Sizes
in Metric |
From M12 to M90 and 4"
BSP |
|
|
